The Siegmund Positioner has an Infinitely Adjustable Vertical/Height Adjustment with Hydraulic Rotary and Tilt Functions. Made Specifically for Clamping of Components on Siegmund U-Squares.
\n THE SIEGMUND SYSTEM 16 IMPERIAL SERIES
THE SIEGMUND SYSTEM 16 IMPERIAL SERIES
M-POSITIONER IS IDEAL FOR ANY WELDING, ASSEMBLY, AND MAINTENANCE TASK.
The Siegmund Positioner has an Infinitely Adjustable Vertical/Height Adjustment with Hydraulic Rotary and Tilt Functions. Made Specifically for Clamping of Components on Siegmund U-Squares.
\n
![\"\"](\"https://i.shgcdn.com/7053d055-3728-411a-b8e8-3fa2ec162af2/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
![\"\"](\"https://i.shgcdn.com/4ad5c259-62ab-4597-9652-10a302cc8800/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
![\"\"](\"https://i.shgcdn.com/07c3e1c8-68eb-482a-ab37-843960960a0a/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
![\"\"](\"https://i.shgcdn.com/93121d43-a67d-4bff-a120-cbe9f28e0df8/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
![\"\"](\"https://i.shgcdn.com/bc9a92a6-586d-45a4-8155-167c7de2326c/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
![\"\"](\"https://i.shgcdn.com/83ae2d17-39ac-433a-ae9a-023c27c54c22/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
![\"\"](\"https://i.shgcdn.com/33a823b7-781c-417f-a58f-2b01efa18028/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
![\"\"](\"https://i.shgcdn.com/d19a5f4d-78ac-4fbe-989e-bf7e5dfc071c/-/format/auto/-/preview/3000x3000/-/quality/lighter/\")
\n
\n
Accessories Included in Bundle
USM051016.25
for the System 16 Imperial Series M-Positioner MP 500
with 72” U-Shape Square (40 Piece Bundle)
Weight of Bundle: 445 lbs.
Get started right with your new welding table, or easily extend the capabilities of your current welding tables by purchasing a Set of Tooling dedicated to System 16 Bore Holed Siegmund Welding Tables.
\n
\n
Accessories Included in
Set #5
for the Siegmund System 16 Welding Tables
(117 Pieces)
Total Weight of Set: 245 lbs.
Get started right with your new welding table, or easily extend the capabilities of your current welding tables by purchasing a Set of Tooling dedicated to 16mm (0.63\") Bore Holed Siegmund Welding Tables.
\n
Accessories Included in Bundle
USM051016.25
for the System 16 Imperial Series M-Positioner MP 500
with 72” U-Shape
(40 Piece Bundle)
Weight of Bundle: 445 lbs.
Get started right with your new welding table, or easily extend the capabilities of your current welding tables by purchasing a Set of Tooling dedicated to System 16 Bore Holed Siegmund Welding Tables.
US6M050016
Quantity: 1
System 16 Imperial (Inch) Series MP 500 M-Positioner
US160386.P
Quantity: 1
(6') 72\" X 4\" X 4\" Square U-Shape (Plasma Nitrided)
US160610
Quantity: 10
Professional Screw Clamp (Burnished / Nitrided)
US160511
Quantity: 16
Short Fast Clamping Bolt (Burnished)
US160560.N
Quantity: 16
Short Connecting Bolt (Nitrided)
US160105.N
Quantity: 8
1\" X Stop and Clamping Square (Nitrided)
US160134.N
Quantity: 2
24\" GK Left Stop And Clamping Square (Nitrided)
US160136.N
Quantity: 2
24\" GK Right Stop And Clamping Square (Nitrided)
\n
PRODUCTIVITY
• Rapid Alignment of Workpieces.
• Optimum Ergonomic Positioning Offers Maximum Productivity.
• One Set-up for Rotating.
• Reduced Down Time.
\n
TECHNICAL CHARACTERISTICS
• Force Transmission through a Bearing with Integrated Gear.
• Drive Manually via Hand Wheel.
• Universal Flange for Clamping of Siegmund U-Squares. (U-Shapes Sold Separately)
\n
ERGONOMICS
• Convenient Access to Component Delivers Best Product Performance.
• Reduced Risk of Repetitive Strain Injury.
\n
IMPROVED QUALITY
• Improved Quality with Flexible Positioning (Flat Position).
• Improved Quality through Maximum Access.
\n
HEAVY-DUTY SQUARE U-SHAPES
• A Multitude of Clamping Combination Options with Squares and Stops by the Five-Sided Bore Holes.
• Supports Squares up to 72\" in Length.
• Each Square is Connected with Connecting Bolts for a Secure Hold.
\n
\n
Specs and Features
of the M-Positioner for
System 16 Imperial (Inch) Series
Item No. US6M050016
\n \n
\n
Specs & Features
of the M-Positioner
for System 16
Imperial (Inch) Series
Item No. US6M050016
\n\n
\n
Welding Table Specs and Features:
Item No. US6M050016
- Weight Positioner Approx.: 243 lbs.
- Gear ratio: 1:73
- Axis of rotation: Horizontal
- Hand Wheel with Handle: Ø 8\"
- Turning Movement: 74 lbf·ft
- Max. Length Square U-Shape: 72\"
- Drive: Manual
- Square U-Shape Compatibility: System 16 Imperial Series
Working Height (A): 33-1/2\"
Tower Height (B): 37-5/8\"
Total Height (C): 42-5/8\"
Base Plate Width (D): 20\"
Base Plate Length (E): 15-3/4\"
USM051016.26: System 16 Imperial Series M-Positioner MP 500 with 72” U-Shape Square - 40 Piece Bundle (2026 SPECIAL PROMOTION)
