The 2-280647.1.PA Prism Ø80 90° with screwed-in collar offers a lightweight, non-marring clamping solution for Siegmund System 28 setups. Its polyamide construction is ideal for working on scratch-sensitive materials, while the 90° geometry provides stable support for pipes up to 100mm (3.94" Inches) in diameter, as well as rectangular profiles.
- The 80mm (3.15" Inches) diameter base provides reliable clamping stability.
- Its 40mm (1.57" Inches) height ensures accurate alignment.
- Weighing only 0.42 lbs. (0.19 kg.), it is lightweight and easy to handle.
- Polyamide construction protects delicate and coated materials.
- The M16 screwed-in collar ensures secure fastening and repositioning.
- Prism extensions allow height adjustment when needed.
Key Features:
- Polyamide build prevents surface damage on scratch-sensitive materials.
- 90° geometry provides secure clamping for both round and rectangular pipes.
- Lightweight construction supports frequent repositioning in setups.
- Fully compatible with Siegmund System 28 boreholes and prism extensions.
Specifications:
- Item No.: 2-280647.1.PA
- System: Siegmund System 28 Metric Series
- Height: 40mm (1.57" Inches)
- Diameter: 80mm (3.15" Inches)
- Weight: 0.42 lbs. (0.19 kg.)
- Material: Polyamide
- Thread: M16 (compatible with prism extensions, e.g., Item No. 280649)
Common Uses:
The 2-280647.1.PA Prism Ø80 90° is used for clamping pipes and rectangular profiles on scratch-sensitive materials such as polished metals, coatings, or aluminum surfaces. Its lightweight polyamide design ensures portability and ease of use while maintaining secure stability in Siegmund System 28 welding environments.
